Recently, the production team at TUYAO PACKAGING wrapped up final quality inspections on a TY-DXGF16-16-5 3-in-1 isobaric filling monoblock, which has now been securely packaged and dispatched to our carbonated beverage customer in Russia. Built specifically for PET bottled sparkling drinks, this custom-configured machine handles both 500ml and 1.25L bottle formats, supporting the client’s plan to scale up production and expand their regional product portfolio.
This shipment marks another successful delivery to the Russian beverage market, where TUYAO PACKAGING has built a reputation for reliable filling equipment, responsive after-sales support and locally adaptable solutions. For this project, the client required a compact, cost-effective monoblock that could deliver consistent filling quality for carbonated products while allowing quick changeovers between two popular bottle sizes. After reviewing multiple layouts and capacity options, they selected the TY-DXGF16-16-5 for its proven isobaric technology, hygienic design and straightforward maintenance.
The TY-DXGF16-16-5 integrates bottle rinsing, isobaric filling and screw capping into a single synchronized monoblock frame. This design eliminates intermediate conveyor sections between separate machines, reduces footprint on the production floor, and minimizes CO₂ loss and product contamination risk during transfer.
With 16 rinsing stations, 16 precision isobaric filling valves and 5 constant-torque capping heads, the machine is sized for steady mid-volume production. It uses a true isobaric filling principle: each bottle is first pressurized with CO₂ to equalize pressure with the filling tank, before product flows gently down the bottle wall. This process drastically reduces foaming, minimizes carbonation loss and ensures consistent fill levels across every bottle — critical for carbonated soft drinks, sparkling water and other gas-containing beverages.
All product-contact components are manufactured from food-grade 304 stainless steel, polished to a smooth, crevice-free finish that supports fast, thorough cleaning and full CIP compatibility. The conveyor and guide rail system is profiled for both 500ml and 1.25L PET bottles, with simple manual adjustment to switch between formats. This flexibility allows the Russian client to run multiple SKUs on a single line, without investing in separate equipment for each bottle size.
The machine also features PLC central control with a touchscreen HMI, real-time fault detection, automatic counting and built-in production safeguards such as no-bottle no-fill and no-cap auto-stop. Key electrical and pneumatic components are sourced from internationally recognized brands, ensuring long-term reliability and easy access to spare parts in the client’s local market.
Before any machine leaves our workshop, it goes through a full factory acceptance test (FAT) protocol. For this TY-DXGF16-16-5 unit, our engineering team ran continuous test verifying filling accuracy, capping torque, speed stability and safety interlock function. Only after all performance parameters met our quality standards did we move into the packaging phase.
For international shipments, proper packaging is just as important as machine quality. Long transit times, uneven loading and humidity changes can damage precision equipment if not properly protected. At TUYAO PACKAGING, we follow a standardized export packaging process for every overseas order, refined over years of shipping machinery to global markets.
The entire machine is first wrapped in multiple layers of stretch film to seal out dust, moisture and sea air. Critical protruding parts such as valve manifolds, control panels and pipe connections are fitted with foam edge protectors to absorb impact during transport. The complete unit is then mounted on a heavy-duty IPPC-compliant wooden pallet, reinforced with bottom bracing and integrated lifting points for safe forklift handling and container loading.
The side view below gives a clearer look at how we secure the full machine footprint for transit.
From this angle, you can see the full depth of the machine and the reinforced pallet structure that supports its weight evenly across the container floor. We also secure all loose accessories, spare parts and document folders inside the machine cabinet, so everything arrives together with the main unit and nothing is lost in transit.
This level of packaging attention comes from real-world experience. We know that for our customers, a damaged machine on arrival means delayed production, lost revenue and extra costs. Our packaging process is designed to prevent those issues, so the equipment arrives in the same condition it left our factory.
Shipping the machine is only the first step. Once the equipment arrives at the client’s facility in Russia, TUYAO PACKAGING will provide on-site commissioning support. Our experienced service technicians will travel to the production site to handle installation, calibration and trial production runs. We will also provide hands-on training for the client’s operators and maintenance staff, covering daily operation, format changeover, routine cleaning and basic troubleshooting.
This full-service approach is one of the main reasons beverage producers continue to work with TUYAO PACKAGING. We don’t just sell equipment — we support the entire lifecycle of the line, from initial layout planning to after-sales spare parts supply and technical support. For our Russian clients, we also offer documentation and support in both English and Russian, to remove language barriers and speed up problem resolution.
For this particular project, we have already shared detailed site preparation guidelines with the client, including foundation requirements, power supply specifications and compressed air parameters. This ensures their facility is fully ready by the time the machine arrives, minimizing lead time from delivery to first commercial production.
Whether you’re setting up a new bottling line or expanding existing capacity, TUYAO PACKAGING has a proven range of 3-in-1 isobaric filling machines for PET bottled carbonated drinks, sparkling water, beer and other sparkling beverages. We offer capacities from 2,000 to 24,000 bottles per hour, with customizable configurations for different bottle sizes, cap types and production layouts.
Every machine is built to the same quality standards, tested in-house before delivery, and backed by our global after-sales support network. We work directly with each customer to match the right solution to their production needs, budget and growth plans.
If you’re planning a carbonated beverage bottling project and would like to discuss equipment options, layout design or pricing, send us your requirements today. Our engineering team will get back to you with a tailored proposal and detailed specification sheet.
